Object Naming Service (ONS)
5
Version 1.0
6

7

8

9

10
EPCglobal Ratified Specification
11
Version of October 4, 2005
12

Copyright Š2005 EPCglobal IncTM , All Rights Reserved.

13
Abstract
14
This document specifies how the Domain Name System is used to locate authoritative
15
metadata and services associated with a given Electronic Product Code (EPC). Its target
16
audience is developers that will be implementing Object Naming Service (ONS)
17
resolution systems for applications.
18
Status of this document
19
This section describes the status of this document at the time of its publication. Other
20
documents may supersede this document. The latest status of this document series is
21
maintained at EPCglobal. This document was ratified by the EPCglobal Board of
22
Governors on October 4, 2005.
23
Comments on this document should be sent to the EPCglobal Software Action Group
24
(SAG) mailing list ([email protected]).
25

26

27

28

29

30

Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
2

65
15
Appendix C -- Service Field Registrations (non-normative) .................................. 23
66
15.1 Registration
Template..................................................................................... 23
67
15.2 Service
Registrations...................................................................................... 24
68

69

Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
4

70
1 Introduction
71
This document specifies how the Domain Name System is used to locate authoritative
72
metadata and services associated with the SGTIN portion of a given Electronic Product
73
CodeTM (EPC). Its target audience is developers that will be implementing Object
74
Naming Service (ONS) resolution systems for applications. Future work by the ONS
75
Working Group will address how ONS is used for the other namespaces that make up
76
the EPC and that are outlined in the EPCglobal Tag Data Standard
77
[Tag Data Standards].
78
2 Terminology and Typographical Conventions
79
Within this specification, the terms SHALL, SHALL NOT, SHOULD, SHOULD NOT,
80
MAY, NEED NOT, CAN, and CANNOT are to be interpreted as specified in Annex G of
81
the ISO/IEC Directives, Part 2, 2001, 4th edition [ISODir2]. When used in this way,
82
these terms will always be shown in ALL CAPS; when these words appear in ordinary
83
typeface they are intended to have their ordinary English meaning.
84
All sections of this document are normative, except where explicitly noted as non-
85
normative.
86
The following typographical conventions are used throughout the document:
87
ˇ ALL CAPS type is used for the special terms from [ISODir2] enumerated above.
88
ˇ Monospace type is used to denote programming language, UML, and XML
89
identifiers, as well as for the text of XML documents.
90
Placeholders for changes that need to be made to this document prior to its reaching
91
the final stage of approved EPCglobal specification are prefixed by a rightward-
92
facing arrowhead, as this paragraph is.
93
3 Background Information (non-normative)
94
This document draws from the previous work at the Auto-ID Center, and we would like to
95
recognize the contributions of the following individuals: Joe Foley (MIT), Erik Nygren
96
(MIT), Sanjay Sarma (MIT), David Brock (MIT), Sunny Siu (MIT), Laxmiprasad Putta
97
(OATSystems), Sridhar Ramachandran (OATSystems). The following papers capture
98
the contributions of these individuals:
99
Engels, D., Foley, J., Waldrop, J., Sarma, S. and Brock, D., "The Networked Physical
100
World: An Automated Identification Architecture" Proceedings of the 2nd IEEE
101
Workshop on Internet Applications (WIAPP '01), 76-77, 2001.
102
The Object Name Service Technical Manual, Version 0.5 (Beta)
103
http://www.autoidlabs.org/whitepapers/MIT-AUTOID-TM-004.pdf
104
4 EPCglobal Network Architecture (non-normative)
105
Radio Frequency Identification (RFID) is a technology used to identify, track and locate
106
assets. The vision that drives the developments of EPCglobal is the universal, unique
107
identification of individual items. The unique number, called an EPC (Electronic Product
108
Code) will be encoded in an inexpensive RFID tag. The EPCglobal NetworkTM will also
109
capture and make available (via the Internet and for authorized requests) other
110
information that pertains to a given item to authorized requestors.
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
5

111
4.1 Electronic Product Code (EPC)
112
The EPCglobal Network architecture provides a method for the inclusion of commercial
113
(both physical and otherwise) products within a network of information services. This
114
architecture makes several axiomatic assumptions, the most important being that it
115
should leverage existing Internet technology and infrastructure as much as possible. As
116
such, it adheres to the "hour glass model" [Willinger and Doyle] of the Internet by
117
standardizing on one identifier scheme: the Electronic Product Code (EPC).
118
In most situations the EPC will denote some physical object. EPC identifiers are divided
119
into groups, or namespaces. Each of these namespaces corresponds to a particular
120
subset of items that can be identified. For example, XML Schemas are denoted using
121
the `xml' namespace, raw RFID tag contents are kept in the `raw' namespace. The `id'
122
namespace is generally reserved for EPCs that can be encoded onto RFID tags and for
123
which services may be looked up using ONS. This `id' namespace is further subdivided
124
into sub-namespaces corresponding to different naming schemes for physical objects,
125
including Serialized GTINs, SSCCs, GLNs, etc. These namespaces are defined
126
normatively in the EPCglobal Tag Data Standards [TAG Data Standards].
127
Each of the sub-namespaces that are defined by the Tag Data Standard have a slightly
128
different structure depending on what they identify, how they are used, and how they are
129
assigned. The SGTIN is used to identify an individual product that is assigned by the
130
company that creates that product. Thus the SGTIN contains an EPC Manager Number,
131
an Object Class, and a Serial Number. Other sub-namespaces such as the SSCC go
132
directly from the EPC Manager Number to the Serial Number and have no concept of an
133
"Object Class". This document only specifies the ONS lookup mechanism for the SGTIN
134
sub-namespace. As such, in many cases its statements about concepts such as "Object
135
Class" or "Serial Number" are specific to the SGTIN namespace and should not be
136
construed as applying to all EPC namespaces. Specifications for those other
137
namespaces are the subject of future work within the ONS Working Group.
138
In order to further leverage the use of Internet derived technology and systems, the EPC
139
is encoded as a Uniform Resource Identifier (URI). URIs are the basic addressing
140
scheme for the entire World Wide Web and ensure that the EPC Network is compatible
141
with the Internet going forward.
142
While an addressing scheme by itself is useful, it can only be used within a network
143
when a mechanism is provided to authoritatively look up information about that
144
identifier [RFC 2826]. This EPC `resolution' mechanism is called the Object Naming
145
Service, or ONS and is what forms the core integrating, or `truth' verifying, principle of
146
the EPCglobal Network.
147
4.2 EPCglobal Network Software Architecture Components
148
The EPCglobal Network Architecture as in Fig. 1 shows the high-level components of
149
the EPCglobal Network. This section highlights and makes reference to The EPCglobal
150
Network Architecture Framework Version 1, July 2005. Available on the EPCglobal
151
website at:
152
http://www.epcglobalinc.org/standards_technology/Final-epcglobal-arch-20050701.pdf
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
6

153

154

Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
7

155

Figure 1: EPCglobal Network Architecture: Components and Layers
156
Components in blue are "roles", not discrete pieces of software. Components in green
157
are interfaces used between two roles. The yellow components labeled "ERP"
158
correspond to locations where one or more ERP systems might provide or interface with
159
a particular role. These components from the figures above are described in the sections
160
below:
161
ˇ Readers
162
Make multiple observations of RFID tags while they are in the read zone.
163
ˇ Reader Protocol Interface
164
Delivers raw tag reads from Readers to Middleware. Events at this interface say
165
"Reader A saw EPC X at time T."
166
ˇ Middleware
167
Accumulates and filters raw tag reads
168
ˇ ALE Interface
169
Delivers consolidated, filtered tag read data from Middleware to Local Application.
170
Events at this interface are "At Location L, between time T1 and T2, the following
171
EPCs were observed" where the list of EPCs has no duplicates and has been filtered
172
by appropriate criteria.
173
ˇ EPC Capturing Application
174
Recognizes the occurrence of EPC-related business events, and delivers these as
175
EPCIS data
176
ˇ EPCIS Capture Interface
177
Provides a path for communicating EPCIS events generated by EPCIS Capturing
178
Applications to other roles that require them, including EPCIS Repositories, internal
179
EPCIS Accessing Applications, and Partner EPCIS Accessing Applications.
180
ˇ EPCIS Repository
181
Records EPCIS-level events generated by one or more EPCIS Capturing
182
Applications, and makes them available for later query by EPCIS Accessing
183
Applications.
184
ˇ EPCIS Query Interface
185
Provides means whereby an EPCIS Accessing Application can request EPCIS data
186
from an EPCIS Repository or an EPCIS Capturing Application, and the means by
187
which the result is returned.
188
ˇ EPCIS-Accessing Application
189
Software that carries out overall enterprise business processes, such as warehouse
190
management, shipping and receiving, historical throughput analysis, and so forth,
191
aided by EPC-related data.
192
ˇ Local ONS
193
Fulfills ONS lookup requests for EPCs within the control of the enterprise that
194
operates the Local ONS; that is, EPCs for which the enterprise is the EPC Manager.
195
ˇ EPCIS Accessing Application
196
An EPCIS-enabled Application of a trading partner. Partner Applications may be
197
granted access to a subset of the information that is available within the enterprise.
198
ˇ Tag Data Translation Schema
199
Provides a machine-readable file that defines how to translate between EPC
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
8

200
encodings defined by the EPC Tag Data Specification. EPCglobal provides this file
201
for use by End-users, so that components of their infrastructure may automatically
202
become aware of new EPC formats as they are defined.
203
ˇ Manager Number Assignment
204
Ensures global uniqueness of EPCs by maintaining uniqueness of EPC Manager
205
Numbers assigned to EPCglobal Subscribers
206
ˇ Object Name Service (ONS) Root
207
A service that, given an EPC, can return a list of network accessible service
208
endpoints that pertain to the EPC in question. ONS does not contain actual data
209
about the EPC. It only contains the network address of services that contain the
210
actual data. ONS is also authoritative in that the entity that has change control over
211
the information about the EPC is the same entity that assigned the EPC to the item
212
to begin with. For example, in the case of an SGTIN EPC, the entity having control
213
over the ONS record is the owner of the SGTIN manager number (EAN.UCC
214
Company Prefix).
215
ˇ EPC Discovery Service(s)

216
A "search engine" for EPC related data. A Discovery Service returns locations that
217
have some data related to an EPC. Unlike ONS, in general a Discovery Service may
218
contain pointers to entities other than the entity that originally assigned the EPC
219
code. Hence, Discovery Services are not universally authoritative for any data
220
they may have about an EPC. It is expected that there will be multiple competitively-
221
run Discovery Services and that some of them will have limited scope (regional,
222
facility wide, etc).
223
ˇ Subscriber Authentication (Core Service-TBD) not yet defined by EPCglobal
224
Architecture Framework.
225
It is important to remember that this is only one view of the EPCglobal Network
226
architecture. Many of the components can be folded into one single piece of software. In
227
certain applications only a few of the roles are actually needed. Even other applications
228
may need components that are either not represented for simplicity (i.e. security) or are
229
not sufficiently developed by the EPCglobal community (i.e. peer to peer based pub/sub
230
event notification).
231
5 ONS Introduction
232
This rest of this document is concerned with specifying the Object Naming Service
233
component discussed above. In keeping with the assumption that the EPCglobal
234
Network architecture should leverage existing Internet standards and infrastructure,
235
ONS uses the Internet's existing Domain Name System [DNS] for looking up (resolving)
236
information about an EPC. This means that the query and response formats must
237
adhere to the DNS standards, meaning that the EPC will be converted to a domain-
238
name and the results must be a valid DNS Resource Record.
239
Important terminology note: the usage of the terms "ONS" and "DNS" may seem
240
arbitrary but they are not. The term DNS is used when the discussion is generally
241
applicable to the DNS system. ONS is used when the discussion is specifically about
242
querying the DNS for an EPC. For example, a query for an MX record is a DNS query. A
243
query to locate an EPC-IS server for an EPC would be called an ONS query, even
244
though the query is carried out using DNS.
245
Additionally, it is important to outline the difference between a "service" and a "server". A
246
service is a set of functions that accomplish some task. That set of functions may
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
9

247
actually be implemented using one or more networked computer systems acting in
248
concert. A good example is the concept of a "Local ONS", or what is commonly referred
249
to as a local caching nameservice. In most situations this service is provided by two
250
physically separate servers that act as backups for one another. For information on how
251
to build highly reliable DNS services the reader is directly at numerous industry texts on
252
robust network design.
253
5.1 The Domain Name System (DNS) (non-normative)
254
While not normative, this section is for readers who may be more familiar with systems
255
such as EDI or UCCnet than basic Internet systems that are normally `invisible' to even
256
the most Internet savvy user.
257
In order to correctly understand DNS and how it is used it is important to understand the
258
system from two important viewpoints. The first is from the viewpoint of the client
259
application that is querying DNS. The second is the viewpoint of an entity publishing
260
data into DNS to be used by a client.
261
5.1.1 Client's View
262
From a client's standpoint the DNS is a black box. Questions go in and answers come
263
out. Where the answer came from, how long it can be cached, and what sequence of
264
delegations it took to find the answer are all hidden from the client application that issued
265
the query. Even the concept of being "hidden" isn't strong enough to convey the concept
266
since some applications would be tempted to "peak under the hood". Since DNS
267
conveys information such as valid Time To Live and where authoritative answers came
268
from within the actual wire protocol, an application cannot recover enough information by
269
peeking under the hood to ensure that it is using the correct responses. Therefore it is
270
considered an extremely dangerous and potentially disastrous thing to attempt to be
271
smarter than the existing DNS implementations.
272
The practical consequence of this is that the DNS API that client applications will use to
273
perform an ONS query is actually very simple. There are only three pieces of information
274
needed: the nameserver to ask, the domain-name in question, and the type of record
275
that is being requested. The first item, the nameserver to ask, is configured as part of the
276
computer's basic network configuration and usually is not something the client developer
277
should concern themselves with. For example, on a computer that has a properly
278
configured network, the following snippet of Java code is all that is required to issue a
279
DNS query and retrieve the results:
DirContext ictx = new InitialDirContext();
Attributes attrs = ictx.getAttributes("dns:///smtp.example.com", new String[] {"MX"});
280

281
The "smtp.example.com" is the domain-name and the "MX" is the record type that is
282
being requested. When done the "attrs" variable will contain the hostname for the MX
283
server for the "smtp.example.com" domain. All of the various DNS issues of root servers,
284
caches, secondaries, etc are hidden from the client application.
285
5.1.2 Publisher's View
286
While client applications are happily able to ignore how the DNS infrastructure actually
287
works, the data the client is consuming must be provisioned by someone in a way that is
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
10

288
scalable, secure and accurate. DNS is a system of hierarchically organized servers that
289
roughly follow the hierarchy found in the domain-name. The top of this hierarchy is the
290
DNS Root, often referred to as simply "." or "dot". Entries in the root are called "top level
291
domains" or TLDs such as "com", "net", "kr", "us", etc. For each delegation, or point at
292
which there is a "dot" in a domain-name, there is a delegation to domains lower in the
293
hierarchy. Generally speaking, for each delegation there is a corresponding network
294
server that contains data for that subsection of the hierarchy. This is why DNS is called a
295
"distributed network database". In the previous example of "smtp.example.com" the
296
delegation of servers would look like this:
297

DNS Root
contains a pointer to the ".com
servers"
".com" nameservers contains an "NS"
record for "example" that points to
Example Corp's nameserver
"example" zone
contains the actual "MX"
record for "smtp"
298

299
A "zone" is considered to be the data that a nameserver publishes. In many situations a
300
single nameserver can contain multiple zones but it can still be thought of as just a
301
physical collection of logical `nameservers'. If the example were for
302
"smtp.department.region.example.com" then the hierarchy of nameservers would
303
naturally be extended to show these further levels of the hierarchy.
304
This hierarchy of nameservers is used to make the data available. In addition to these
305
servers there are what are called "caching nameservers". In many cases the caching
306
nameserver and an enterprises public nameserver are the same thing but logically
307
they're separate functions. A caching nameserver creates network efficiencies by
308
keeping commonly retrieved records as close to the querying client as possible. Some
309
operating systems (generally Unix variants) have caching nameservers built in. But most
310
desktop operating systems offload this responsibility onto a departmental or enterprise
311
wide caching nameservers. Generally speaking, most operating systems discover this
312
network configuration information via DHCP.
313
5.2 ONS's Usage of DNS
314
In order to use DNS to find information about an item, the item's EPC must be converted
315
into a format that DNS can understand, which is the typical, "dot" delimited, left to right
316
form of all domain-names. The ONS resolution process requires that the EPC being
317
asked about is in its pure identity URI form as defined by the EPCglobal Tag Data
318
Standard [TAG Data Standard] (e.g., urn:epc:id:sgtin:0614141.100734.1245).
319
Since ONS contains pointers to services, a simple A record (or IP address) is insufficient
320
for today's more advanced web services based systems. Therefore ONS uses the
321
Naming Authority PoinTeR (or NAPTR) DNS record type. This record type contains
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
11

322
several fields for denoting the protocol, services and features that a given service
323
endpoint exposes. It also allows the service end point to be expressed as a URI, thus
324
allowing complex services to be encoded in a standard way.
325
Figure 3 describes a typical ONS query from start to finish from the viewpoint of a client
326
application:
RFID
TAG
Tag Encoded EPC
Local System
7
TAG
Reader
2
1
3 URI Conversion
4 ONS Resolver
5
8
Local caching
nameserver
EPC-IS Server
6
HTML Page
DNS Cloud
327

328

329
Figure 3: A typical ONS query.
330
A sequence of bits denoting an EPC is read from a 64-bit RFID tag.
331
Example:
332
(10 000 00000000000000 00000000000000011000 0000000000000000110010000)
333
The tag Reader sends that sequence of bits to a local server. Example:
334
(10 000 00000000000000 00000000000000011000 0000000000000000110010000)
335
The local server converts the bit sequence into the pure identity URI Form
336
as defined in Section 4.3.3 of the EPCglobal Tag Data Standard [TAG
337
Data Standards]. Example:
338
urn:epc:id:sgtin:0614141.000024.400
339
The local server presents the URI to the local ONS Resolver. Example:
340
urn:epc:id:sgtin:0614141.000024.400
341
The resolver converts the URI form into a domain-name and issues a
342
DNS query for NAPTR records for that domain. Example:
343
000024.0614141.sgtin.id.onsepc.com
344
The DNS infrastructure returns a series of answers that contain URLs that
345
point to one or more services (for example, an EPCIS Server). (See
346
Section 10 for examples.)
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
12

347
The local resolver extracts the URL from the DNS record and presents it
348
back to the local server. Example:
349
http://epc-is.example.com/epc-wsdl.xml
350
The local server contacts the correct EPC-IS server found in the URL for
351
the EPC in question
352
Future Note (non-normative): It is expected that the work of theEPCglobal Tag Data
353
Translation Working Group, when complete, will provide both a formal representation of
354
the transformation procedure above, as well as automated software procedures to carry
355
it out.
356
5.2.1 Serial Number Level Queries to the ONS
357
It is important to note that this version of ONS does not specify queries for what is
358
normally considered the fully serialized SGTIN. It specifically stops at the "Object
359
Class" level. Subsequent queries for information about a given serial number must be
360
resolved by querying the application layer server designated by the ONS results. The
361
ability to specify an ONS query at the serial number level of granularity as well as the
362
architectural and economic impacts of that capability is an open issue that will be
363
addressed in subsequent versions of this document. Its lack of mention here should not
364
be construed as making that behavior legal or illegal.
365
6 ONS Nameserver Infrastructure Organization (non-
366
normative)
367
The previous section covered DNS and how ONS uses DNS from a client point of view.
368
What it did not cover was the processes and procedures for making ONS data available
369
in the proper form for the client. The main issues are the delegation hierarchy and zone
370
maintenance.
371
6.1 ONS Delegation Rules
372
Since ONS is specifically for looking up EPC related services it must follow the
373
delegation rules for the various namespaces that may be part of an EPC. As mentioned
374
in the Introduction, this specification is limited to the SGTIN namespace. Thus, while the
375
concept of delegations discussed below is generally applicable, the specific delegation
376
rules are specific to SGTINs.
377
An SGTIN is a serialized version of a GTIN. GTINs are part of the EAN.UCC System of
378
product codes. In most of the namespaces that are part of this System there is the
379
concept of an EAN.UCC Company Prefix. Company Prefixes are generally assigned by
380
either GS1 (formerly EAN International) or GS1 USTM (formerly the Uniform Code
381
Council, Inc.) depending on the country the registrant in question belongs to. As part of
382
the deployment of the EPCglobal Network, GS1 and GS1 US have formed a joint
383
venture to handle the various management duties of the network, one of which is
384
coordinating the assignment of Company Prefixes and the provisioning of those prefixes
385
in ONS.
386
Remembering from above that where there is a "dot" there is a delegation step, the "dot"
387
that exists between the product code, the company prefix, and "sgtin.id.onsepc.com"
388
means that there is a delegation step, and thus a pointer to a subsequent zone (and
389
possibly a separate nameserver).
390

Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
13

EPCglobal, Inc Nameservers
ONS Root
contains all delegation pointers (NS
records) for the nameserver for all
Company Prefixes
sgtin.id.onsepc.com
"0614141" nameserver contains the
Prefix Owner's Nameserver
zone file for all product codes that
belong to the "0614141" EAN.UCC
Company Prefix
0614141.sgtin.id.onsepc.com
0614141.sgtin.id.onsepc.com zonefile
000024 "EPC+epics" http://....
000025 "EPC+epics" http://....
000045 "EPC+epics" http://....
Contains this zone file
391

392
Thus, in order for a company to provision their GTINs with ONS, they must request that
393
this be done through either GS1 US or the appropriate GS1 affiliate. The request is sent
394
to EPCglobal IncTM which follows its procedures for determining the contents of the NS
395
record that will appear in the "sgtin.id.onsepc.com" zone. That NS record will contain the
396
IP addresses of the nameservers that the owner of that Company Prefix has specified.
397
Once these IP addresses are available in the "sgtin.id.onsepc.com" zone queries will be
398
routed to the Company Prefix owner's nameservers and at that point they can determine
399
which Item Reference codes to publish information about.
400
Other EAN.UCC namespaces may have different rules so the above should not be
401
applied to namespaces such as SSCCs or GLNs until the Software Action Group
402
publishes the appropriate standards for those namespaces.
403
6.2 Zone Maintenance Guidelines
404
There are numerous operational guidelines for maintaining DNS nameservers that are
405
either freely available or come with commercial DNS software. Many of these are
406
specific to the BIND derived lineage of nameservers but the guidelines are generally
407
applicable to any nameserver. DNS server software breaks down to two general
408
categories: servers that maintain their zone data as text based configuration files and
409
those that use sophisticated backend databases.
410
Many nameservers can synthesize records based on business rules rather than
411
configuration files. Some companies may have complicated structure within their product
412
codes in order to segregate by division or region. In such cases nameserver
413
administrators may utilize "synthesized records" to determine the actual values returned.
414
Whether or not a nameserver synthesizes its answers from business rules or reads them
415
directly from a text file is irrelevant to how ONS works and is a hidden, server-side
416
optimization.
417
7 ONS Formal Specification
418
The formal specification of ONS is a set of procedures and rules to be followed by ONS
419
Clients and ONS Publishers. An ONS Client is an application that wishes to use ONS to
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
14

420
identify a service that may provide information about a specific EPC. An ONS Publisher
421
is an entity responsible for making services available to ONS Clients by creating service
422
pointer entries in an ONS Server. An ONS Server is an implementation of a DNS Server;
423
because ONS differs from DNS only in what data is provided by the server, not in the
424
operation of the server itself, there is no separate specification for an ONS Server. Any
425
DNS server compliant with [DNS] and [RFC 3403] may be used as an ONS Server.
426
The ONS specification consists of three ingredients:
427
ˇ A procedure (Section 8) that an ONS Client MUST follow in order to present a query
428
to ONS. This procedure specifies how an EPC is converted to a DNS NAPTR query.
429
ˇ A set of rules (Section 9) that ONS Publishers MUST follow to represent ONS
430
information (namely, pointers to services for EPCs) as DNS NAPTR records within
431
an ONS Server.
432
ˇ A procedure (Section 10) that an ONS Client MUST follows in order to interpret the
433
results of an ONS query. This procedure specifies how an ONS Client can locate a
434
service using the information provided by the ONS Server.
435
8 DNS Query Format
436
The following specifies the procedure an ONS client MUST follow to present a query to
437
ONS.
438
ˇ Begin with an EPC represented in the pure identity URI form as
439
defined in Section 4.1 of the EPCglobal Tag Data Standards [TAG
440
Data Standards]. URIs in this form are ASCII strings beginning with
441
urn:epc:id:, for example,
442
urn:epc:id:sgtin:0614141.000024.400.
443
Follow the procedure below to convert the URI into a domain name
444
ending with .onsepc.com. For example,
445
000024.0614141.sgtin.id.onsepc.com.
446
Use a DNS resolver to query for DNS Type Code 35 (NAPTR) records for
447
the domain name from Step 2. The method for obtaining and using
448
the DNS resolver is outside the scope of this specification. It is
449
anticipated that this will be addressed through a companion
450
specification that specifies a standard ONS Application Programming
451
Interface (API). Even when a standard ONS API exists, however, an
452
ONS Client MAY use any DNS resolver conforming to [DNS], using
453
whatever API is available.
454
Follow the procedure in Section 10 to interpret the results from Step 3.
455
In order to query the DNS for the EPC, the URI form specified above must be converted
456
to domain name form in Step 2. The procedure for this conversion is as follows:
457
ˇ Begin with an EPC represented in the pure identity URI form as
458
defined in Section 4.3.3 of the EPCglobal Tag Data Standard [TAG
459
Data Standard]. For example,
460
urn:epc:id:sgtin:0614141.000024.400.
461
Remove the urn:epc: prefix (in the example, leaving
462
id:sgtin:0614141.000024.400).
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
15

463
Remove the serial number field. In all tag formats currently defined in
464
[TAG Data Standard] (SGTIN, SSCC, SGLN, GRAI, GIAI, and GID),
465
the serial numer field is the rightmost period (.) character and all
466
characters to the right of it. (In the example, this leaves
467
id:sgtin:0614141.000024)
468
Replace each colon (:) character with a period (.) character (in the
469
example, leaving id.sgtin.0614141.000024)
470
Invert the order of the remaining period-delimited fields (in the example,
471
leaving 000024.0614141.sgtin.id)
472
Append .onsepc.com. In the example, the result is
473
000024.0614141.sgtin.id.onsepc.com.
474
9 DNS Records for ONS
475
ONS contains pointers to authoritative information for EPCs. Each such pointer takes
476
the form of a DNS Type Code 35 (NAPTR) record. This section specifies how ONS
477
Publishers must encode information into NAPTR records.
478
The contents of a DNS NAPTR record are logically formatted as follows:
479

Order Pref Flags Service
Regexp
Replacement
0 0
u EPC+epcis
!^.*$!http://example.com/cgi-bin/epcis!
. (a period)
480

481
ONS Publishers MUST obey the following rules:
482
ˇ The
Order field MUST be zero.
483
Explanation (non-normative): The Order field is used in DNS applications where a
484
series of regular expressions from distinct NAPTR records are applied consecutively to
485
an input. ONS does not currently make use of this feature but future requirements may
486
force a re-evaluation of always specifying this number as zero. Implementers are
487
strongly encouraged to follow the DDDS algorithm as specified in [RFC 3401].
488
ˇ The
Pref field MUST be a non-negative integer. The value of the Pref field is an
489
ordinal that specifies that the service in one record is preferred to the service in
490
another record having the same Service field. An ONS Client SHOULD use attempt
491
to use a service having a lower Pref number before using an equivalent service
492
having a higher Pref number.
493
ˇ The
Flags field MUST be set to 'u', indicating that the Regexp field contains a URI.
494
ˇ The
Service field contains an indicator of the type of service that can be found at the
495
URI in question. This feature allows for the ONS service to indicate different service
496
end points for different classes of service. The value of the Service field MUST
497
consist of the string EPC+ followed by the name of a service registered with the
498
EPCglobal Network Protocol Parameter Registry. The Service field identifies what
499
type of service is accessible through the URL provided by the Regexp field of this
500
record. See Section 10 for examples of service types, and Section 15 for a list of
501
services that make up an initial set of registered service classes.
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
16

502
ˇ The
Replacement field is not used by the EPCglobal Network but since it is a
503
special DNS field its value is set to a single period ('.') instead of simply a blank.
504
ˇ The
Regexp field specifies a URL for the service being described. The value of this
505
field MUST be the string !^.*$! (the six character sequence consisting of an
506
exclamation point, a caret, a period, an asterisk, a dollar sign, and another
507
exclamation point), followed by a URL, followed by an exclamation point (!)
508
character.
509
Explanation (non-normative): In previous versions of ONS the result was simply an IP
510
address. This proved insufficient due to the needs of protocols such as SOAP that are
511
layered over HTTP. In nearly all modern protocols there is a need for a hostname and
512
additional 'path' information. The reason the field is in the form of a regular expression is
513
that the NAPTR record is used by other applications that have the need to conditionally
514
rewrite the URI to include other information. While none of the examples here make use
515
of this feature, it has not been determined if this will always be the case. In the future it
516
may become necessary to allow full regular expression and replacement functions within
517
the regexp field. Therefore, implementers would be wise to not assume that the URI can
518
simply be extracted without any regular expression processing.
519
The general form of the Regexp field is as a Posix Extended Regular Expression. This
520
form states that the first character encountered is the field delimiter between the regular
521
expression and the replacement portion of the entire rewrite expression. In the above
522
example the delimiter is the exclamation point (!) character. The regular expression
523
portion is ^.*$ which equates to 'match anything'. The replacement portion is
524
http://example.com/cgi-bin/epcis. The choice of '!' as the delimiter
525
instead of a more traditional '/' makes the entire line much easier to read and less error
526
prone.
527
In a future version of this specification, if regular expression processing becomes
528
necessary, the input to the regular expression processor would be the original canonical
529
EPC URI, before transforming to an onsepc.com domain name.
530
10 Processing ONS Query Responses
531
ONS Clients MUST use the following procedure to interpret the results returned by an
532
ONS query as formulated in Section 8.
533
ˇ The result from the ONS query is a set of NAPTR records as
534
described in Section 9.
535
From among the results from Step 1, select those records whose Service
536
field names the desired service. If there is no such record, stop: a
537
pointer to the desired service is not available from ONS for the
538
specified EPC.
539
From among the results from Step 2, select those records having the
540
lowest value in the Pref field.
541
From among the results from Step 3, select a record at random.
542
Extract the service URL from the record from Step 4, by extracting the
543
substring between the initial !^.*$! and the final ! character.
544
Attempt to use the service URL from Step 5.
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
17

545
If Step 6 is not successful, go back to Step 4, using a different record
546
from among the records from Step 3. If all records from Step 3 have
547
been tried, go back to Step 3 using records from Step 2 having the
548
next lowest value in the Pref field. If all records from Step 2 have
549
been tried, stop: no service is available.
550
11 Examples (non-normative)
551
In the following examples the EPC in question is
552
urn:epc:id:sgtin:0614141.011015.583865 which represents an Example Corporation
553
Model 100 Widget.
554
The ONS Client application attempts to learn about this product by first following the
555
procedure in Section 8, which converts the EPC into a domain-name:
556
011015.0614141.sgtin.id.onsepc.com
557
The application then queries the DNS for NAPTR records for that domain name and
558
receives the following records:
Order Pref Flags Service
Regexp
Replacement
0 0
u EPC+ws !^.*$!http://example.com/autoid/widget100.wsdl!
.
0 0
u EPC+epcis
!^.*$!http://example.com/autoid/cgi-bin/epcis.php!
.
0 0
u EPC+html
!^.*$!http://www.example.com/products/thingies.asp! .
0 0
u EPC+xmlrpc
!^.*$!http://gateway1.xmlrpc.com/servlet/example.com! .
0 1
u EPC+xmlrpc
!^.*$!http://gateway2.xmlrpc.com/servlet/example.com! .
559

560
Each of these records conforms to the rules specified in Section 9.
561
Finally, depending on the service that the ONS Client desires, it uses one or more of the
562
records returned to locate an appropriate service. The following sections describe
563
specific examples of services an ONS Client might locate. In each case, the ONS Client
564
uses the procedure specified in Section 10 to locate a service, using the records
565
returned above.
566
11.1 Finding a WSDL file for a product
567
One of the simplest but most powerful examples is where an ERP application is Web
568
Services [Web Services] enabled. This particular application is capable of learning about
569
new products by making various application specific web services calls to public
570
interfaces made available by the manufacturer. In this case the application can simply
571
use the ONS to look to see if a WSDL file exists that describes the Web Services it
572
requires.
573
The application issues the query and receives the NAPTR records above. It iterates
574
through the list looking for the 'ws' service which designates a WSDL file that defines the
575
available web services. It locates that service in the first record and returns the URI
576
found in the Regexp field. The application then hands that URI to its Web Services
577
engine to determine if the proper end points exist. If they do then the application
578
requests the metadata it needs and proceeds with its processing.
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
18

579
11.2 Finding an authoritative EPCIS server for a product
580
This example shows how an EPC can be used to retrieve a pointer to an EPCIS server
581
that contains authoritative metadata about a product. Again, using the same results from
582
above, the client uses the second record and extracts the URI from the Regexp. It then
583
uses that URI as the end point to send the EPCIS query to.
584
11.3 Finding an HTML formatted web page description of a
585
product
586
This example shows how a very lightweight service can be deployed almost immediately
587
using nothing more than an existing externally available corporate web server containing
588
existing product content. By inserting the third record in the results list above, Example
589
Corp can easily point applications to authoritative product data without any modifications
590
to their systems. Applications that understand this service can be very lightweight, using
591
existing web browsers to display the content.
592
11.4 Finding an XML-RPC gateway to the Web Service interfaces
593
In some cases a service may be outsourced. In this example Example Corp has decided
594
not to expose an XML-RPC [XML-RPC] service of its own. Instead there is an XML-RPC
595
to SOAP gateway run by a third party. In the interest of interoperability Example Corp
596
simply adds an ONS entry that points to this gateway, thus enabling new applications
597
with little effort on their part.
598
In this case there are two records for this service and both have the same Order value.
599
This means that the Pref field is used to indicate a preference for one over the other
600
(load balancing and fail-over). If for some reason the record with the Pref of '0' fails or is
601
busy, the one with the Pref of '1' can be used.
602

603
12 References
604
Willinger and Doyle
605
Willinger, W. and Doyle, John. Robustness and the Internet: Design and
606
evolution, 2002. (See http://netlab.caltech.edu/pub/papers/part1_vers4.pdf)
607
EPC
608
Brock, David. The Electronic Product Code (EPC): A Naming Scheme for
609
Physical Objects, 2001. (See http://www.autoidlabs.org/whitepapers/MIT-
610
AUTOID-WH-002.pdf)
611
RFC 2826
612
(Internet Architecture Board). RFC 2826: IAB Technical Comment on the Unique
613
DNS Root, 2000. (See http://www.ietf.org/rfc/rfc2826.txt)
614
DNS
615
(Internet Engineering Task Force). STD0013, RFC 1034, RFC 1035, ed
616
Mockapetris, P. 2000. (See http://www.ietf.org/rfc/std/std13.txt)
617
Web Services
618
(WorldWideWeb Consortium). Web Services Activity, 2000. (See
619
http://www.w3.org/2002/ws/)
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
19

620
XML-RPC
621
Winer, Dave. XML-RPC Specification, 1999. (See http://www.xml-rpc.com/spec)
622
RFC 2396
623
T. Berners-Lee, R. Fielding, L. Masinter. Uniform Resource Identifiers (URI):
624
Generic Syntax, 1998. (See http://www.ietf.org/rfc/rfc2396.txt)
625
RFC 3401
626
Mealling, Michael. Dynamic Delegation Discovery System (DDDS) Part One: The
627
Comprehensive DDDS, 2002. (See http://www.ietf.org/rfc/rfc3401.txt)
628

629

630
RFC 3402
631
Mealling, Michael. Dynamic Delegation Discovery System (DDDS) Part Two: The
632
Algorithm, 2002. (See http://www.ietf.org/rfc/rfc3402.txt)
633
RFC 3403
634
Mealling, Michael. Dynamic Delegation Discovery System (DDDS) Part Three:
635
The Domain Name System (DNS) Database, 2002. (See
636
http://www.ietf.org/rfc/rfc3403.txt)
637
Registry
638
Mealling, Michael. EPC Network Protocol Parameter Registry, 2002. (See
639
http://www.ietf.org/rfc/rfc3403.txt)
640
TAG Data Standards
641
EPCglobal, "EPC Tag Data Standards Version 1.1 Rev.1.24," EPCglobal
642
Standard Specification, April 2004,
643
http://www.epcglobalinc.org/standards_technology/EPCTagDataSpecification11r
644
ev124.pdf.
645

646
13 Appendix A Glossary (non-normative)
647
Auto-ID
648
"Automatic Identification" -- An open, global network that can identify anything,
649
anywhere, automatically.
650
Domain-name
651
A hierarchical, 'dot' (.) separated namespace used to identify hosts on the
652
Internet
653
DNS
654
See Domain Name Service
655
Domain Name Service
656
An infrastructure level Internet service used to discover information about a
657
domain name. It was originally developed to map a host name to an IP address,
658
but has since been extended to other uses (such as ENUM, which maps a phone
659
number to one or more communication services.
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
20

660
EPC
661
See Electronic Product Code
662
EPCIS
663
EPC Information Service A series of EPC Network specific standards defining
664
various methods of data exchange and metadata lookup.
665
Electronic Product Code
666
An abstract namespace made up of an EPC Manager Number, an Object Class
667
code, and a Serial Number, or a subset thereof.
668
EPC Manager Number
669
A code that identifies a manufacturer of objects
670
ONS
671
See Object Name Service
672
ONS Root
673
The domain-name that is appended to the manager id and which acts as the `top'
674
of the DNS tree that contains all of the EPC entries. This root domain is
675
"onsepc.com"
676
Object Name Service
677
A resolution system, based on DNS, for discovering authoritative information
678
about an EPC
679
Object Class code
680
A code that identifies a particular type of object that is created by a particular
681
manufacturer
682
NAPTR
683
"Naming Authority PoinTeR" -- A DNS record type (35) that contains information
684
about a specific delegation point within some other namespace using regular
685
expressions.
686
PML
687
"Physical Markup Language" -- generally information obtained from a Reader or
688
similar sensor
689
Reader
690
A radio enabled device that communicates with a tag
691
RFID
692
"Radio Frequency Identification" -- A method of identifying unique items using
693
radio waves. The big advantage over bar code technology is lasers must see a
694
bar code to read it. Radio waves do not require line of sight and can pass
695
through materials such as cardboard and plastic.
696
Regular Expression
697
A standard language for pattern matching within a string of characters and for
698
composing new strings based on matched subcomponents of the original string
699
(i.e. a search and replace function)
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
21

700
Serial Number
701
A number that identifies a particular instance of an object class.
702
tag
703
A microchip and antenna combo that is attached to a product. When activated by
704
a tag Reader the tag emits its EPC plus other data it may have
705
URI
706
"Uniform Resource Identifier" -- the superclass of all identifiers that follow the
707
'scheme:scheme-specific-string' convention as specified in RFC 2396 [RFC2396]
708
(e.g., "urn:isbn:2-9700369-0-8" or "http://example.com/news.html")
709
URL
710
"Uniform Resource Locator" -- A deprecated term usually used to denote the
711
subclass of URIs that contain DNS domain-names in their authority section.
712
14 Appendix B -- DDDS Application Specification (non-
713
normative)
714
The use of NAPTR records is governed by a series of RFCs that define something called
715
the Dynamic Delegation Discovery Service. RFC 3401 [RFC 3401] is the first in the
716
series and provides an introduction to the series. In order to safely use NAPTR records
717
on the public network a specification must exist that describes the values of the various
718
fields. This appendix contains that specification which, when approved by the SAG
719
process, will be extracted and published as an RFC itself.
720
14.1 Application Unique String
721
The Application Unique String is the EPC in URI form.
722
14.2 First Well Known Rule
723
The First Well Known Rule is the identity function. The output of this rule is the same as
724
the input. This is because the EPC namespace and this Applications databases are
725
organized in such a way that it is possible to go directly from the name to the smallest
726
granularity of the namespace directly from the name itself.
727
14.3 Expected Output
728
The output of the last Rewrite Rule is a URI and a Service designator that, together,
729
designate an application context (server and application) that will expose some
730
metadata or services about the EPC.
731
14.4 Valid Databases
732
At present only one DDDS Database is specified for this Application. RFC 3403 [RFC
733
3403] specifies a DDDS Database that uses the NAPTR DNS resource record to contain
734
the rewrite rules. The Keys for this database are encoded as domain-names. The
735
conversion method for this database is as follows:
736
1. Remove the 'urn:epc:' header
737
2. Remove the serial number field
738
3. Invert the order of the remaining fields
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
22

739
4. Convert all `:' characters to `.'
740
5. Append ".onsepc.com"
741
14.5 Valid Flags
742
The 'u' flag which denotes that the current Rule is terminal and that the output of the
743
Regexp is a URI.
744
14.6 Service Parameters
745
The Service parameters for this Application take the form of a string of characters with
746
the following ABNF:
747
service_field = "EPC+" service_name
748
service_name = ALPHA *31ALPHANUM
749
The valid values for 'service_name' and the process for registering new services are
750
found in the ONS Service Registry discussed in Appendix C. It is important to note that
751
the "+" character is not allowed in a service_name. This allows for future expansion of
752
the service field if it becomes apparently that service_names may need parameters.
753
15 Appendix C -- Service Field Registrations (non-
754
normative)
755
The 'service_name' portion of the Service field is a managed space where the values
756
that are available for use are found in the EPCglobal Network Protocol Parameters
757
Registry. The goal is to balance the ability to innovate with new services with the desire
758
for interoperability between services. If the service_name simply ends up denoting non-
759
interoperable, proprietary services then the total value of the system is significantly
760
reduced. Conversely, limiting all services to simply those that are standardized by the
761
EPCglobal SAG standards process limits the ability of the system to innovate.
762
To balance these requirements a special sub-class of services is created which start
763
with an 'x-'. Services of this type do not need to be registered but merely act as a
764
designation of "experimental status". Implementers should not create services in this
765
class and then never register them. This method has been utilized within the MIME
766
Content-Type registry for years and while there are instances of "x-" entries becoming
767
common, this is becoming less common as the process is streamlined.
768
The Registry entry for ONS Service types will be created with the /ons/service_name/
769
pathname. Files in that directory will be named after Service Name field in the template
770
followed by the `.txt' file extension. The contents of the file will be the template supplied
771
for the registration. For example, the `epcis' template below would be found at
772
http://onsepc.com/ons/service_name/epcis.txt and would contain the just the fields
773
mentioned below. Registrations are First Come First Served. Registration requires a
774
published Recommendation from EPCglobal.
775
15.1 Registration Template
776
A document specifying a service_name must contain the following template. This
777
template is then entered into the registry as soon as the document is published.
778
Service Name:
779
The exact sequence of characters that will appear in the Service field
Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
23

780
Functional Specification:
781
A pointer to publicly available documentation for the service.
782
Valid URI schemes:
783
A list of registered URI schemes that are valid for this service (e.g. web services
784
can be specified using either the 'http:' or 'https:' scheme)
785
Security Considerations:
786
Any security issues associated with use of this service
787
15.2 Service Registrations
788
The following are initial services that will be registered as soon as this document is
789
published as a specification:
790
ˇ Service Name: epcis
791
Functional Specification: The EPC Information Service Specification
792
Valid URI schemes: http, https
793
Security Considerations: See the Security Considerations section of the EPC
794
Information Service Specification
795
ˇ Service Name: ws
796
Functional Specification: A generic Web Services [Web Services] based service
797
where the application must negotiate what services are available by investigating the
798
WSDL file found at the URI in the Regexp
799
Valid URI schemes: http, https
800
Security Considerations: Web Services utilize a great deal of existing Internet
801
infrastructure and protocols. It is very easy to use some of them in insecure ways.
802
Any usage of Web Services should be done in the context of a thorough
803
understanding of the dependencies, especially as it relates to the DNS and HTTP.
804
ˇ Service Name: html
805
Functional Specification: Simply returns a URI that will resolve to an HTML page
806
on some server. The assumption is that this page contains information about the
807
product in question.
808
Valid URI schemes: http, https, ftp
809
Security Considerations: None not already inherent in the use of the
810
WorldWideWeb.
811
ˇ Service Name: xmlrpc
812
Functional Specification: A URI that denotes an HTTP POST capable service on
813
some server that is expecting XML-RPC [XML-RPC] compliant connection.
814
Valid URI schemes: http, https
815
Security Considerations: None not already inherent in the use of the
816
WorldWideWeb.
817

Copyright Š 2005 EPCglobal IncTM, All Rights Reserved.
24
